Key Specifications (Example: Onward 6 Passenger Electric/HP/HP Lithium):
Power:
Electric: 250 Amp DC Motor Controller, 3.3 hp (2.4 kW) rated; Peak 13 hp (9.6 kW), (6) 8-volt batteries.
HP Electric: 375 Amp AC Motor Controller, 22.4 hp (16.5 kW) Peak, (6) 8-volt batteries.
HP Lithium: 375 Amp AC Motor Controller, 29 hp (21.4 kW) Peak, 4kw or 7kw Lithium-Ion batteries.
Speed: Maximum speed of 19 mph (30 kph) for most models.
Steering & Suspension:
Steering: SportDrive™ — Self-compensating double reduction helical rack & pinion.
Front Suspension: Independent leaf spring with dual hydraulic shocks (Electric/HP/HP Lithium/Gas).
Rear Suspension (for some models like 4 Forward Lifted HP Lithium-Ion): Patent pending with track bar and automotive grade jounce bumpers.
Brakes: 4-wheel mechanical drum brakes with a foot-actuated, 3-position park brake.
Body & Tires:
Body and Finish: Front: Painted TPO; Rear: Painted Surlyn.
Tires: 205 x 55 – 10 Tubeless (Electric/HP/HP Lithium) or 23 x 10 – 10 Tubeless (for some lifted models).
Dimensions (Example: 2025 Onward 4 Forward Lifted HP Lithium-Ion): Length: 133 in. (375.9 cm); Width: 51.3 in. (130.5 cm); Total vehicle weight: 1,113 lb.
Seating: Available in 2, 4, or 6 passenger configurations.
