The Club Car Onward is available in various configurations, including gas and electric (lithium-ion or flooded lead-acid) powertrains, and 2 or 4-passenger models. Specifications can vary depending on the specific model and year, but general features and options include:
Powertrain Options:
Gas: 429cc Kohler, Overhead Valve (OHV) with EFI, 14.0 hp (10.3 kW) rated.
High-Performance Electric (Lithium-Ion): 3.1 kWh Lithium-Ion battery, 375 Amp AC Motor Controller, 29 hp (21.4 kW) Peak, up to 19 mph (30 kph) top speed.
Flooded Lead-Acid Electric: Standard electric option.
Chassis & Suspension:
Frame: AlumiCore™ — Ladder-style aluminum box beam.
Steering: SportDrive™ — Self-compensating double reduction helical rack & pinion.
Front Suspension: Independent A-arms with Hydraulic shocks (HP Electric) or Independent leaf spring w/ dual hydraulic shocks (High-Performance Electric).
Rear Suspension: Patent pending w/ Track Bar and Automotive Grade Jounce Bumpers (HP Electric).
Dimensions & Weight (Example for 4 Passenger HP Lithium):
Overall Vehicle Size (LxWxH): 108 x 48.75 x 71 inches (274.3 x 123.8 x 180.3 cm).
Wheelbase: 65.5 inches (166.4 cm).
Ground Clearance: 4.5 inches (11.4 cm).
Total Weight: 784 lb (355.6 kg).
Features & Accessories:
Monsoon Canopy™ Top designed to channel water away.
Premium stitched seating and tinted fold-down windshield.
Hidden storage compartment/cooler in the rear.
Locking glove box with keys.
Optional backup camera, Occupant Protection System, glass windshield, USB-A & USB-C charging ports, and versatile cupholders on LSV models.
LED headlights, tail/brake lights, turn signals, speedometer, state of charge indicator, and on-charge indicator for electric models.
Various wheel and tire options, including 10″ Mercury Wheels with Loadstar Tires (non-lifted) and 14″ Mercury Wheels with Kraken Tires (lifted).
